MOXA V2416-XPE Industrial Computer

CPU Intel Atom N270 1.6 GHz
Pre-installed Windows Embedded Standard 2009
2 x 10/100 Mbps Ethernet ports
4 x RS-232/422/485 Serial ports
Aluminum body design
12 to 48 VDC input power range (24 VDC for EN 50155)
DIN rail, Wall, and VESA mounting
-25 to 60°C operating temperature range

Brand: MOXA
Model: V2416-XPE

0 reviews • Write a review

Datasheet

Operating Temperature (-25 to 60°C)
Relative Humidity (5 to 95% non-condensing)
Shock (EN50155 standard)
Vibration (EN50155 standard)

Factory Automation
Railway Transportation

$0.00

Ex Tax: $0.00

Buy Now ENQUIRE NOW

Add to Wish List Compare this Product

Tags: Industrial Computing , x86 Computers , Industrial Computers , Wide Temperature Computers , Factory Automation Products , Railway Transportation Products , Computers , MOXA V2416 Series

The V2416 Series embedded computers are based on the Intel Atom N270 x86 processor and feature 4 RS-232/422/485 serial ports, dual LAN ports, and 3 USB 2.0 hosts. In addition, V2416 computers provide VGA and DVI-I outputs and are compliant with a portion of EN 50155 specifications, covering operating temperature, power input voltage, power surges, ESD, and vibration, making them particularly well-suited for railway and industrial applications.

The CompactFlash socket, SATA connectors, and USB sockets provide the V2416 computers with further reliability, perfect for industrial applications that require data buffering and storage expansion. Most importantly, V2416 computers have key enhancements for mass storage media, such as two hot-swappable SATA drive trays for convenient and fast storage maintenance, user-programmable LEDs, and an API that simplifies customizing mass storage monitoring and management. Lastly, Moxa's MDM API is also included, giving users a convenient gateway-client model that eases the distributed automation and control of multiple devices by a single host device.

V2416 series computers come pre-installed with a choice of Linux, Windows Embedded Standard 2009, or Windows Embedded Standard 7, giving our customers their choice of software environments for developing platform applications.

End of Life Product - No Replacement

Please note that the V2416 Series has been phased out. You can explore the V2406C Series, V2201 Series, V3200 Series, and V2403C Series in the x86 Computers.

Experience the convenient way to purchase the MOXA V2416-XPE Industrial Computer in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Our sales experts will provide the most helpful information about the price and sale conditions for a wonderful buying experience.

Industrial Computer : Computer
CPU	Intel Atom N270 1.6 GHz processor
Supported OS	Windows Embedded Standard 2009
OS (pre-installed)	Windows Embedded Standard 2009
System Memory	1 GB pre-installed, 1 slot of 200-pin DDR2-533 SO-DIMM SDRAM
Graphics Controller	Intel Generation 3.5 Integrated Graphics Engine, 250 MHz core render clock and 200 MHz core display clock at 1.05-V core voltage
Storage Slot	Built-in: 2 GB onboard industrial DOM to store OS, Storage Expansion: 1 type I/II CompactFlash slot for memory expansion, HDD Support: 2 hot-swappable SATA-II connectors for mass storage, with removable trays
Industrial Computer : Interface
LAN	2 x 10/100 Mbps ports (M12 connector)
Magnetic Isolation Protection	-
Digital Input/Output Channels	6 x Digital Input Channels (Source type)
Serial Ports	4 x RS-232/422/485 ports (DB9 male connector)
USB	3 bootable USB 2.0 ports: 2 type A, 1 M12
Expansion Slot	-
Industrial Computer : Serial Communication Parameters
Baudrate	50 bps to 921.6 Kbps (non-standard baud rates supported)
Data Bits	5, 6, 7, 8
Stop Bits	1, 1.5, 2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485
Industrial Computer : Serial Signals
RS-232	TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422	TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w	TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w	Data+, Data-, GND
Industrial Computer : LED Indicators
System	Indicators for power, storage, plus 2 programmable LEDs on each storage tray
LAN	2 on each port: 100 Mbps & 1000 Mbps
Serial	2 on each serial port: 1 Tx & 1 Rx
Industrial Computer : Power Requirements
Input Voltage	12 to 48 VDC (M12 connector), (Compliant with EN 50155 on 24 VDC)
Input Current	2.16 A @ 12 VDC, 1.08 A @ 24 VDC, 542 mA @ 48 VDC
Power Consumption	26 W
Industrial Computer : General
Alert Tools	-
Automatic Reboot Trigger	Built-in WDT (watchdog timer) supporting 1-255 level time interval system reset, software programmable
MTBF	-
Industrial Computer : Physical Characteristics
Dimensions	Without ears: 154 x 250 x 86 mm (6.06 x 9.84 x 3.38 in), With ears: 154 x 275 x 92 mm (6.06 x 10.83 x 3.62 in)
Housing	Aluminum
Operating temperature	(without HDD installed) -25 to 60°C (-13 to 140°F)
Storage Temperature	(without HDD installed) -40 to 85°C (-40 to 185°F)
Relative humidity	5 to 95% (non-condensing)
Standards and Certifications	Safety: UL 60950-1, CSA C22.2 No. 60950-1-07, EN 60950-1; EMC: EN 55022 Class A, EN 61000-3-2 Class D, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class A; Green Product: RoHS, CRoHS, WEEE; Rail Traffic: EN 50155, EN 50121-2-3, EN 50121-4, IEC 61373
Weight	4 kg
Mounting	DIN rail, wall, VESA
